Peerless Electronics introduces three new vehicle power distribution modules from its Cole Hersee Division of Littelfuse Commercial Vehicle Products, including the PDM31001ZXM, PDM21001LXM, and BPDMA104HXF1.
The HWB Series that includes PDM31001ZXM and PDM21001LXM are hard-wired modules designed for use with 280 style components (mini-fuses, relays, diodes, and resistors). They feature 18 or 60 cavities that create a high density fuse module with a compact footprint.
These units allow you to customize the circuitry, and the wires plug into the back of the module using sealed Delphi Metri-Pack Series 280 tanged terminals. The units are IP67-sealed, making them more reliable in extreme environments so they can to be installed anywhere on the vehicle.
The BPDMA104HXF1 is a 2+2 MINI Fuse and the JCASE Holder accommodates two MINI fuses and two JCASE fuses. The use of these fuse types provides an amperage range of 2-60A in a compact package.
The four fuses are bussed internally to the main input power stud which allows you to reduce wiring by making one input connection to power the four fuse circuits. The 2+2 holder is a sealed module.
