Ranger Division of BendPak introduced the R980DP tire changer
— the first Ranger swing-arm tire changer with two power assist arms, plus a new bead roller and exclusive features, according to the company's press release. The machine is designed to tackle everything from low-profile, run-flat and high-performance tires to oversized truck wheels and off-road assemblies with speed and precision.
Reduce Physical Strain on Techs While Helping to Improve Their Efficiency
The R980DP’s right-side assist arm features a new bead roller to do the hard work of pressing down stiff beads to create room for the tire iron when demounting, as well as keeping beads below the beak of the toolhead when mounting.
The left-side articulating arm is equipped with a multi-function bird-shaped head that serves primarily as a traveling drop-center tool designed to accommodate a wide range of wheel edge profiles. It can also be used as tire hook, lending a helping hand to maneuver heavy or stubborn tires during service.
The R980DP features an ergonomic, operator-friendly layout, with upfront controls designed for easy access, improving workflow and reducing fatigue.
Slide on the hold-down-head accessory to facilitate outside clamping on low-profile tire/wheel combos or to act as a safety restraint device during inflation.
High-Torque, High-Speed Electric Turntable for Efficiency Improvements
A 3-horsepower motor delivers a 20% increase in turntable speed and 43% more rated torque than other models, letting technicians change tires on virtually any passenger vehicle wheel more quickly, according to the release. For shops without 220-volt access, the R980DP-L 110-volt model offers the same features in a plug-and-play design with a standard turntable.
Built-in features including Ranger’s TurboBlast Bead Seating System mean the R980DP is ready to deliver maximum productivity as soon as it’s installed, with no need for additional accessories. The handheld TurboBlast Bead Seater can be placed directly in the bead to deliver a powerful burst of air exactly where it’s needed.
The R980DP features a bead breaker auto assist device to further reduce physical strain on the machine operator. After the pneumatic-powered blade penetrates the bead, the Bead Breaker Auto Assist Device smoothly dislodges and retracts the blade from the tire. This eliminates the need to manually yank out stuck blades, even on tight-fitting wheels.
Ergonomic, Operator-Friendly layout, with Upfront Controls for Easy Access
The 45 mm spring-assisted hex tool shaft and hardened outrigger arm provide stability and accuracy, ensuring proper tool head positioning for damage-free operation. No-Mar RimGuard wheel clamps securely accommodate wheels from 9 to 30 inches without damaging delicate finishes.
The hardened steel mount/demount head prevents bead damage with its micro-smooth surface, while the protective polymer mount/demount head and plastic protector kit eliminate metal-to-metal contact, safeguarding powder-coated, alloy and high-end wheels.
Industrial-grade pneumatic control valves and high-pressure polyurethane pneumatic tubing deliver smooth airflow and durability. Forged steel pedals stand up to heavy shop use while a maintenance-free gearbox incorporates a large oil and grease reservoir to ensure efficient heat dissipation.
The R980DP and R980DP-L are available as stand-alone equipment purchases or with the new Ranger Select package that includes professional installation and training.
