Bobcat’s 3600 and 3650 are the first utility vehicles in the Bobcat lineup to offer cabs with heat and air conditioning. The machines feature 24.8-hp engines, four-wheel disc brakes, and front Dual A-Arm and rear De Dion suspension. Cargo box capacity is 1,250 pounds, and top speed is 30 mpg.
A characteristic of the hydrostatic system is dynamic braking, which occurs when the operator releases pressure on the travel pedal. As the operator lets up on the travel pedal, a valve in the drive motor closes — blocking the flow of oil — which in turn slows the machine down at a similar rate. This dynamic braking feature also makes the utility vehicle easier to control when under load. For greater stopping force, the utility vehicles’ four-wheel disc brakes can be applied.
For daily maintenance, access to key components is important. The fuel tank on the 3600 and 3650 utility vehicles is conveniently located and daily checks of items such as fluids, filters, and the battery can be made through easy access to the engine compartment. Liquid-cooled engines in Bobcat utility vehicles protect critical engine components from overheating, which also results in more power and performance from the machine, because components are kept cooler at higher rpms.
The 3650 is the industry’s first utility vehicle with the capacity to operate front-mounted PTO attachments, according to Bobcat. This provides users with a higly versatile machine designed to fill the gap between standard Bobcat utility vehicles and the larger Toolcat utility work machines.
QuickLook: Bobcat 3600 Utility Vehicle
Transmission: Hydrostatic
Drive system: 4x4 and AWD
Horsepower: 24.8 hp diesel
Integrated attachment: Bobcat snow blade
Accessories: Sprayer
Multi-Attachment X-Change™ (M.A.X.)
Total vehicle operating capacity: 2,215 lb.*
Vehicle towing capacity: 2000 lb.
Cargo box load capacity: 1250 lb.
Maximum travel speed: 30 mph
Operating weight: 1955 lb. (without cab)
*The total vehicle operating capacity is the combined weight of passengers, cargo box load and gross trailer weight.
QuickLook: Bobcat 3650 Utility Vehicle
Transmission: Hydrostatic, PTO engagement
Drive system: 4x4 and AWD
Horsepower: 24 hp diesel
Front-mounted attachments: Bobcat bucket, pallet fork and push broom, mower, angle broom, snowblower, snow blade
Front-mounted PTO attachments: Snowblower, mower and angle broom
Accessories: Sprayer
Multi-Attachment X-Change™ (M.A.X.)
Total vehicle operating capacity: 2,215 lb.*
Lift height: 2 ft.
Lift capacity: 500 lb.
Vehicle towing capacity: 2000 lb.
Cargo box load capacity: 1250 lb.
Maximum travel speed: 30 mph
Operating weight: 2215 lb. (without cab)
*The total vehicle operating capacity is the combined weight of passengers, cargo box load and gross trailer weight.
