The upgraded 3.7-cubic-yard interim Tier 4-compliant (iT4) DL250-3 wheel loader features 172 hp, up from 163 hp in its previous design. It is engineered with a breakout force of 27,120 lbs., a full-turn tipping capacity of 20,680 lbs., and a dump height of 9 feet 2 inches.
The DL250-3 is also available in a high-lift configuration, extending the dump height 18 inches above the standard DL250, to 10 feet 8 inches.
This wheel loader’s new auto-idle feature provides additional noise reduction and fuel savings by reducing the working idle of the wheel loader from 950 rpm to a standby idle setting of 750 rpm when the machine is inactive for a short period of time.
The DL250-3 offers operators the ability to set upper and lower limits for both the lift arm and bucket stop positions from inside the cab. Better lifting capabilities improve cycle times in digging and loading applications, while providing better control of the lift arm and bucket positions. An optional fourth spool control valve provides operators the capability to utilize an attachment that requires an additional hydraulic function, e.g., some snowblowers and snow blades.
To keep the wheel loader running at optimal performance in dirty and dusty conditions, the DL250-3 incorporates a new automatic-reversing cooling fan. The operator can manually reverse the fan via a switch, or set it to automatically reverse on a preset time frame. Each time the fan reverses, it will run in reverse for a few minutes to clean the cooling system. This results in longer working hours and shorter maintenance time to clean the cooling system.
Operators can also expect upgraded driving performance options. As an alternative to the standard limited slip differential, the DL250-3 offers an optional hydraulic locking front differential. Based on ground conditions, the operator can choose to lock the differential manually with a floor-mounted foot switch, or allow the machine to automatically engage the system. This provides increased driving power when one wheel spins or loses traction and improves machine performance when navigating tough terrain.
This Doosan wheel loader is equipped with 6-cylinder DL06 diesel engine that has been optimized for use with cooled exhaust gas recirculation (CEGR) system, a diesel oxidation catalyst (DOC), and a diesel particulate filter (DPF). Engines with this configuration are optimized to reduce nitrogen oxides (NOX) and after-treatment is needed to reduce particulate matter, to comply with iT4 emission regulations.
The 360-cubic-inch engine features a high-pressure common-rail (HPCR) design with direct fuel injection, electronic control, and four valves per cylinder. The HPCR system increases the efficiency of fuel delivery via increased pressure. The increased pressure allows the injector to inject a finer mist into the engine, which results in a more efficient combustion that in turn produces more torque and improved fuel economy, less noise, lower operating costs, and cleaner exhaust.
Service intervals on the front lift arm pins have increased fivefold, from 50 to 250 hours, reducing operating costs and downtime. Tilt cylinder hydraulic hoses have been rerouted for improved hose reliability, better hose movement and improved visibility to the attachment.
The DL250-3 — like every new Doosan machine — is covered by a 48-hour parts guarantee. The program guarantees that if a “machine-debilitating” part is needed, Doosan will deliver it directly to the end user within two business days or Doosan will pay for a replacement machine rental. The 48-Hour Parts Guarantee is subject to carrier delivery restrictions and/or governmental agency delays.
QuickLook: Doosan DL250-3 wheel loader
Horsepower: 172 hp
Operating weight: 31,900 lb.
Bucket capacity: 3.7 cu. yd.
Dump height: 9 ft. 2 in.
Breakout force: 27,120 pounds lbf.
