The R330LC-9A HC excavator from Hyundai Construction Equipment Americas, Inc., features certified Tier 4 Interim engine upgrade, improved hydraulics, increased operator comfort, and added durability. A high chassis feature making it an ideal match for forestry applications where maneuvering through piles of timber is essential.
The R330LC-9A HC has an operating weight of 74,960 lbs. and is powered by a 268-hp Cummins QSL9 Tier 4 interim engine. The engine is complimented by Cummins’ VGT Turbocharger, which continuously varies the airflow boost to precisely match engine rpm and load demands for optimal performance. Other innovations such as the variable speed fan clutch, two-stage auto decel system, and the economy mode help to conserve fuel and reduce environmental impact. Plus, operators can choose between three engine modes - Power, Standard, and Economy - which enable the machine to switch between full power and reduced fuel consumption.
R330LC-9A HC | |
Operating Weight lbs (kg) | 74,960 (34,000) |
Bucket Breakout Force lbf, SAE(kN) | 51,700 (230) |
Maximum Dig-Depth ft (mm) | 24’2” (7,370) |
Engine hp (kW) | 268 (200) |
Bucket Capacity cubic yards (cubic meters) | 2.75 (2.10) |
