Case Construction Equipment’s SV340 skid steer is rated at 3,400 lbs. operating capacity and features a bucket breakout force of 9,531 lbs. A 90-hp FPT engine with selective catalytic reduction (SCR) technology powers the machine, eliminating the need for a diesel particulate filter (DPF) and the associated downtime of regeneration. It also allows the engine to run cooler and with greater fuel efficiency as fuel is not used to burn off collected particulate, according to Case.
The SV340 features EZ-EH (electro-hydraulic) controls that provide nine adjustable speed and control sensitivity settings that can be adjusted on the fly. This allows the operator to quickly switch between personalized settings for speed and control, and to tailor machine performance to the application. A single rocker switch allows operators to switch between the Case “H” operating pattern and ISO pattern controls for jobsites where numerous operators with different operating preferences are working. The skid steer also features push-button Ride Control, which cushions loader arm movement for a smoother ride and greater material retention.
The SV340 offers a wide cab and low entry threshold for easy access and greater visibility down to the bucket/attachment. The cab-forward design combines with ultra-narrow wire side screen; a large, rounded rear window, and standard heavy-duty front and side lights to provide all-around visibility.
The SV340’s routine service points are all located at the rear of the machine. Operators can quickly access the engine, filters, fill points, and all other service points through a single point of access. The skid steer also offers Case's easy-tilt cab for convenient access to the drivetrain compartment.
The machine offers optional high-flow (38.7 gpm at 3,450 psi) and enhanced high-flow (35 gpm at 4,000 psi) auxiliary hydraulics for power and attachment versatility. Additional enhancements have also been made to manifold valves, the gear pump, and the auxiliary loader circuit to allow for added power and performance.
The skid steer is compatible with more than 250 attachments.
