Bobcat Company’s Tier 4 T630 and T650 compact track loaders feature 74 hp and provide operators with all of the same performance benefits of the previous interim Tier 4 models. They also meet emissions standards without a diesel particulate filter (DPF).
The Tier 4 Bobcat non-DPF solution was achieved by designing an ultra-low particulate combustion (ULPC) engine. The ULPC is accomplished through a specially designed engine combustion chamber that significantly reduces the amounts of particulate matter created during combustion. Therefore, Tier 4 emissions compliance can be achieved without using a DPF.
In addition to eliminating the need for a DPF, the new engines used in 600 frame-size loaders will have increased torque. This increase in torque is produced over a wide range of engine rpm, allowing operators of all skill levels to better utilize the machines’ maximum performance.
Bobcat provides owners and operators even more simplified maintenance with the new 600-platform loaders. A 500-hour engine oil and filter change interval replaces the previous 250-hour interval to help reduce overall routine maintenance costs. Another maintenance improvement for the machines includes an air filter equipped with a built-in pre-cleaner filter to help extend the life of the filter in high-debris applications. Owners and operators will also benefit from a cartridge-style block heater that is easy to install and use, to assist with engine starts in cold conditions.
The 600 frame-size loaders are ideal for construction and landscaping.
QuickLook: Bobcat T630 Compact Track Loader
Rated operating capacity: 2230 lb. (1012 kg)
Lift path: Radius
Engine: 74 hp Tier 4 turbo diesel (55,2 kW)
Lift height to hinge pin: 10 ft. 1 in. (3 m)
Operating weight: 8742 lb. (3965 kg)
Auxiliary hydraulic flow: 23 gpm (87,1 L/min)
High-flow option: 30.5 gpm (115,5 L/min)
Ground pressure: 4.0 psi with wide tracks (27,6 kPa)
QuickLook: Bobcat T650 Compact Track Loader
Rated operating capacity: 2570 lb. (1166 kg)
Lift path: Vertical
Engine: 74 hp Tier 4 turbo diesel (55,2 kW)
Lift height to hinge pin: 10 ft. 4 in. (3,1 m)
Operating weight: 9321 lb. (4228 kg)
Auxiliary hydraulic flow: 23 gpm (87,1 L/min)
High-flow option: 30.5 gpm (115,5 L/min)
Ground pressure: 4.2 psi with wide tracks (29 kPa)
