The Takeuchi TB210R compact excavator has a minimal tail swing design, retractable undercarriage, a backfill blade that can go from 40.2 inches to 29.5 inches wide, and a foldable ROPS/TOPS canopy that can reduce the machine’s overall height.
The TB210R includes pilot-operated joystick controls with an ISO/SAE control pattern change valve, selector valve, and pilot accumulator. To enhance attachment versatility, the TB210R features a selector valve for one-way and two-way auxiliary hydraulic flow, and the pilot accumulator enables the operator to easily remove residual pressure from the auxiliary lines.
A Kubota D722-E4B three-cylinder engine powers the TB210R, and delivers nearly 22% more hp than its predecessor, the TB108. The engine oil filter and dipstick are easily accessed through a lockable access panel located below the operator’s seat. A lockable swing-out panel on the left side of the machine provides access to the fuel fill and sight gauge, fuel filter with shut-off, and the dual-element air cleaner. In addition, the rear engine hood opens overhead, providing access to the hydraulic tank and sight gauge, battery, coolant reserve tank, pattern change valve, and one-way flow selector valve.
The TB210R features a two-year, 2,000-hour warranty.
