The Terex TL120 compact wheel loader comes with a Tier 4 interim 4-cylinder turbo diesel engine with intercooler, a new Terex Smart Control operating system, a quieter cab offering a better view to the ground for the operator, and a new cooling system.
The wheel loader boasts 101 hp and a Tier 4i Deutz engine that provides the 16,653-lb operating weight TL120 with approximately 16% more power and 90% lower exhaust emissions than its predecessor.
Terex added a new operating concept that makes it easier for the operator to configure the machine precisely to an application. Operation of the Terex Smart Control is similar to menu guides on smart phones. Within the cab, a new dashboard display provides a better at-a-glance of machine operation information, while the multi-function joystick comes with an electro-proportional control circuit and a slow/fast key for precise handling. The keypad has extra-large keys, and all the fuses and relays are now mounted inside the cab for additional protection.
Noise levels in the two-door cab have been cut from 76dB(A) to 71dB(A). The lock switch for the Quick-Attach system is mounted by the steering column, and the operator has a clear view of the attachment coupling process.
A new Tier 4i engine cooling system uses a hydraulically operated and temperature-controlled fan that starts automatically when required to help reduce fuel consumption. Using parasitic reduction, the hydraulically driven fan can be adjusted down to compensate for cool climates. A reverse function is available for machines working in dusty environments to push debris from the radiator, in turn reducing service and associated downtime. The combination of the new cooling package and the revised rear hood cuts exterior noise levels from 102dB(A) to 99dB(A) — making the Tier 4i TL120 ideal for use in urban areas or sites with strict decibel-level requirements.
Other changes include a three-part counterweight which provides easier service access to the engine, the battery isolator is now adjacent to the cab, and beneath the redesigned engine hood are new jump start terminals. A revised steering system reduces the effort needed to turn the wheel while retaining its 15-ft, 4-in turning radius.
Other features carried over from the previous model are the 1.57 yd3 to 2.35 yd3 bucket capacity, parallel kinematics, self-locking differentials, and an oscillating rear axle.
